Water Bottle 1 Ebike Battery Pack 36V 48V 7.8Ah~13.6Ah for Electric Bicycle lithium battery

The battery core uses lithium-ion environmental protection materials, which not only has stable battery performance, but also built-in over voltage, over current, overload, short circuit protection and temperature protection.

Category:

Description

Product information:
Rated Voltage: 36V/48V
Rated capacity: 7.8Ah-13.6Ah optional
BMS: 30A (Motor use within 1000W)
BMS Function: Over-Current ,Over-Discharge , Over-Charge ,Short-Circuit Protection, Balance act.
Material: aluminum shell
Discharge Cut-Off Voltage: 29V/37.7V
Charge Voltage: 42V/54.6V
Charging time: 5-12 hours
Batteries: Brand 18650 cells(Samsung,LG,Panasonic,Sanyo,Chinese A grade cell)
Charging Working Temperature: 0~45°C
Discharge Working Temperature:-20~60°C
Storage Temperature:-10~40°C
Warranty:24 months

Additional information

Model Number

BP-012/Water Bottle

Battery Size

325x110x98mm

Battery Type

LI(NiCoMn)O2 18650

Cycle Life

80% capacity after 800 cycles

OEM/ODM

Acceptable

Application

Ebike(Electric Bicycle),Mountain Bikes
